Key feature:
Support installation of up to 10 fans Support CPU cooler height up to 180 mm Support GPU length up to 425 mm Support a 360 mm radiator at the front Support up to 3 drive bays: 2 x 3.5″ HDD + 1 x 2.5″ SSDColor variants : Black, White
Installed Fan: 3 front, 1 rear
Build & Form Factor
Compatible Motherboards: ATX, Micro‑ATX, and Mini‑ITX
Materials: 0.7 mm SPCC steel; tempered glass front and left side panels for a striking showcase
Dimensions:
Structure: 431 × 245 × 445 mm
Product: 450 × 245 × 475 mm
Package: 540 × 310 × 505 mm
Weight: Net ~6.8 kg; Gross ~8 kg
Cooling Capabilities
Fan Support (up to 10 fans):
Front: 3 × 120 mm or 2 × 140 mm
Top: 3 × 120 mm or 2 × 140 mm
Rear: 1 × 120 mm or 1 × 140 mm
Bottom: 3 × 120 mm or a combo of 14 cm fans
Liquid Cooling: Supports front and top radiators up to 360 mm, including 240 mm and 280 mm options
Hardware Compatibility
CPU Cooler Clearance: Up to 180 mm
GPU Length: Supports graphics cards up to 425 mm
Drive Bay Options: 3.5″ HDD: up to two, plus up to three 2.5″ SSDs (various configurable combinations)
Expansion Slots: 7 standard PCIe slots
Connectivity & Extras
I/O Panel: 1 × USB 3.0, 1 × USB‑C port, and HD Audio jacks
PSU Mount: Standard bottom-mounted ATX power supply (not included)
