Product Details

Build & Form Factor

• Supports M‑ATX motherboards.

• Made from 0.5 mm SPCC steel, with a tempered glass left side panel and a metal mesh front panel for optimal airflow.

• Dimensions:

  1. Structure: 335 × 210 × 404 mm

  2. Product: 365 × 210 × 423 mm

  3. Package: 478 × 275 × 435 mm

• Weight:

  1. Net: ~4.5 kg

  2. Gross: ~4.85 kg

Cooling & Thermal Support

• Fan support:

  1. Front: 3 × 120 mm

  2. Top: 2 × 120 mm

  3. Rear: 1 × 120 mm

• Liquid cooling: Supports a 240 mm radiator at the top.

• Dust Management: Easy-to-remove dust filters on the top, front, and bottom for maintenance.

Hardware Compatibility

• CPU cooler clearance: Up to 165 mm tall.

• GPU length: Supports up to 320 mm.

• Drive bay options:

  1. 2 × 3.5″ HDD + 2 × 2.5″ SSD

  2. OR 1 × 3.5″ HDD + 3 × 2.5″ SSD

• Expansion slots: 4 PCI slots for add‑on cards.

• I/O Panel: USB 3.0 × 1, USB 2.0 × 2, and HD Audio.

• PSU: Bottom-mounted ATX power supply—unit not included.
